4″ Low Pressure Gauge
The low pressure diaphragm gauge offers the pinnacle in both performance and accuracy for pressure and vacuum applications up to and including 10 psi. Such uses include gas-draft indication, air flow & filtration, leak detection, etc.
The LP40L is constructed from a single beryllium-copper diaphragm affixed to a precision machined brass plate. This advanced design, coupled with a high-precision, milled-teeth brass movement, provides the user with a low pressure instrument that is without equal.
300 series Stainless Steel
Polycarbonate or Glass
Aluminum, white finished with black markings
Brass with precision-milled teeth
1/4"NPT or 1/8"NPT
±1.5% Full Scale (exceeds ASME B40.100 Grade B)
-40 to 160° F (-40 to 70° C)
-40 to 140° F (-40 to 60° C)
