3″ Lower Connected Bimetal Thermometer
ELSAMED lower connected bimetal thermometers are ideal for applications requiring a compact dial and fixed lower connection. These tamper-proof instruments are an excellent choice when an external recalibrator or pointer adjustment are not required. The hermetically-sealed, stainless steel case prevents moisture from entering into the instrument and fogging the lens, thus allowing the operator to obtain clear, accurate readings.
CASE:
Hermetically sealed 300 series stainless steel
RING:
Hermetically sealed 300 series stainless steel
LENS:
Double strength glass standard, with polycarbonate (250°F maximum range) optional
DIAL:
Anti-parallax, aluminum with white finish and black markings
POINTER:
Black
RECALIBRATOR:
External recalibrator on back of case.
STEM:
300 series stainless steel, 0.250"
CONNECTION:
300 series stainless steel, 1/2" NPT
ACCURACY:
±1% full range (ASME B40.3 Grade A)
AMBIENT TEMPERATURE:
-40 to 250°F (-40 to 120°C)
